Country of Origin : Malaysia

Features:

• easy installation – just connect to USB and it will work
• double-sided glue tape on panel outline for easy assembly with LCD panel
• mini USB connector for touchscreen with HID protocol
• driver-less single touch (installed by default) functions
• multi-touch up to 5 fingers (available with firmware update) with additional driver
• aspect ratio: 16:10 (widescreen)
• active area: 152mm (H) x 95.5mm (V)
• surface treatment: 3H glass, Glare
• operating temp: -20C … +70C
• storage temp: -30C … +80C

Technical drawing

Firmware version 2.0 (updated 16-Feb-2015)

How to update firmware

Tested to work with:

- Windows 7, 8, 8+
- any Linux distro with kernel >= 3.0 running on any board with USB host (like RaspberryPi, Beaglebone Black, etc)
